Overall weight |
16500kg |
|
Rated load |
5000kg |
|
Engine |
Weichai SteyrWD10G220E21 |
|
Rated power |
162kw |
|
Min fuel-consume ratio |
<213g/kw.h |
|
Maximum tractive force |
167KN |
|
Maximum breakout force |
> 177KN |
|
Maximum grade ability |
30° |
|
Maximum dump height |
3100mm |
|
Maximum dumpreach |
1250mm |
|
Minimum turningradius |
6640mm |
|
Gearbox mode |
planetary |
|
Overall dimension (L×W×H) |
8108×2950×3450mm |
|
Bucket capacity |
3m³ |
|
Gear shift |
2forward shift 1reverse shift |
|
Maximum speed |
38km/h |
