Performance Operating weight: 1530 kg Rated load: 400 kg Bucket capacity: 0.2 m³ Max Speed: 9 km/h Max traction: ≥15 kN Max breakout: ≥7.3 kN Lifting time of boom: 7 s
Engine Manufacturer: Kubota Model: D1105 Rated power: 18.2 kW / 3000 rpm Engine displacement: 1.123 L Emission Standard: Euro V / EPA4
Dimension Overall operating height: 3400 mm Height to bucket hinge pin: 2500 mm Height to top of cab: 1813 mm Height to bottom of level bucket: 2446 mm Without bucket length: 2200 mm Overall length with bucket: 2950 mm Dumping angle at maximum height: 40° Dumping height: 2000 mm Dumping reach: 441 mm Rollback of bucket on ground: 30° Rollback of bucket at full height: 103° Wheelbase: 801 mm Ground clearance: 145 mm Angle of departure: 20° Front turning radius without bucket: 960 mm Front turning radius: 1660 mm Rear turning radius: 1253 mm Rear axle to bumper: 910 mm Tread width: 790 mm Width: 1080 mm Bucket width: 1100 mm
