QG45SL Configurations:
Operating weight: 3100 kg
Rated load: 700 kg
Bucket capacity: 0.4 m³
Max Speed: 12 km/h
Max traction: ≥25.40 kN
Max breakout: ≥18.4 kN
Lifting time of boom: 7 s
Manufacturer: Xinchai
Engine Model: C490BPG
Rated power: 36.7kW/2650rpm
Engine displacement: 2.27 L
Emission Standard: National‑II
Overall operating height: 3980 mm
Height to bucket hinge pin: 3080 mm
Height to top of cab: 2140 mm
Height to bottom of level bucket: 2913 mm
Without bucket length: 2640 mm
Overall length with bucket: 3420 mm
Dumping angle at maximum height: 40°
Dumping height: 2380 mm
Dumping reach: 700 mm
Rollback of bucket on ground: 30°
Rollback of bucket at full height: 104°
Wheelbase: 991 mm
Ground clearance: 185 mm
Angle of departure: 20°
Front turning radius without bucket: 1300 mm
Front tuning radius: 2290 mm
Rear tuning radius: 1440 mm
Rear axle to bumper: 1080 mm
Tread width: 1450 mm
Width: 1720 mm
Bucket width: 1740 mm
