Performance Operating weight: 1330 kg Rated load: 400 kg Bucket capacity: 0.2 m³ Max Speed: 5.6 km/h Max traction: ≥12 kN Max breakout: ≥7 kN Lifting time of boom: 7 s
Engine Model: KubotaD1105 Rated power: 18.2 kW / 3000 rpm Engine displacement: 1.123 L Emission Standard: Euro V / EPA4
Dimension Overall operating height: 2800 mm Height to bucket hinge pin: 2159 mm Height to top of cab: 1685 mm Height to bottom of level bucket: 2831 mm Without bucket length: 2165 mm Overall length with bucket: 2831 mm Dumping angle at maximum height: 30° Dumping height: 1685 mm Dumping reach: 611 mm Rollback of bucket on ground: 30° Rollback of bucket at full height: 103° Wheelbase: 1149 mm Ground clearance: 258 mm Angle of departure: 29° Front turning radius without bucket: 970 mm Front turning radius: 1496 mm Rear turning radius: 1496 mm Rear axle to bumper: 910 mm Tread width: 826 mm Width: 1006 mm Bucket width: 1166 mm
